With the experience we gathered from our popular Bombtrack EXT V1 and V2 forks, and the collective feedback from our customers, we have developed the MGV fork from the ground up. Taking a fresh look at the manufacturing methods of carbon forks, we were able to use innovative new techniques which enabled us to create a lightweight fork with the capacity to carry a lowrider pannier rack and 20 kg of luggage. This feature alone makes the MGV a unique piece of kit, but with a maximum tire clearance of 29 x 2.25, it sets itself apart from the rest of the field and performs like no other.
COLOR
Matt black / Glossy black
MATERIAL
Full UD carbon fiber
STEERER
Tapered, 1-1/8″” – 1-1/2″”, 300 mm length
S.H.I.S. DIMENSIONS
28.6 | 40
OFFSET
53 mm
AXLE TO CROWN
410 mm
HUB SPACING
100 mm
BRAKE
Flat Mount 160, rotor size 160 – 180 mm
INTERNAL ROUTING
Brake hose / dynamo cable
MOUNTS
Triple cage / head light / mudguards / lowrider rack
INCLUDED
Through axle, expander, cable port plugs
WEIGHT
530 g (w/o through axle, w/o bolts, uncut steerer)
TIRE CLEARANCE
58 – 622 (29″” x 2.25″”) / 64 – 584 (27.5″” x 2.5″”)
MAXIMUM SYSTEM WEIGHT
140 kg
EXTRA INFO
Ready for fully internal cable routing, lowrider compatible
FORK STEERER INNER DIAMETER
23.6 mm
CROWN DIAMETER
57 mm
ASTM RIDING CONDITION
2
HUB TYPE
12 x 100 mm
TA TOTAL LENGTH (CLOSED)
120 mm
TA DIAMETER
12 mm
TA THREADING DIAMETER X PITCH
M12 x 1.5
MIN. THREAD LENGTH
14 mm
MAX. DIAMETER HUB ENDCAPS
19 mm
NOTE: The maximum cage mount load refers to the dynamic load that the mounts are exposed to. Forks with mounted cages must be treated with great care. Leaning the bike with the cage against a wall or onto the ground, or hitting obstacles with the cage will result in a dynamic load that exceeds the maximum load by far. Installed cages need to touch the fork blade surface within a radius of 5 mm around the center of the mounting bolt. Some cages might need to use washers between cage and fork blade.
