2023 Synapse 2

Road Reimagined

Roll smooth, roll fast, roll confident. Wherever the road takes you, roll with Synapse – our most comfortable, all-around, up-for-anything, pure road machine.

Where it thrives

The open road, up & down hills, rough pavement

What it’s built for

Comfort, handling, going long

Highlights

• Lightweight SmartForm C2 Alloy Frame w/ full carbon fork
• Shimano Tiagra 10-speed group w/ hydraulic disc brakes
• DT Swiss R470 wheels / 700x30c Vittoria tires
• Fizik Aliante Delta Saddle
• Equipped with Contain top tube bag

Details

• PlatformSynapse
• Model NameSynapse 2
• Model CodeC12602U

Frameset

• FrameLightweight SmartForm C2 Alloy, SmartSense compatible, BSA threaded BB, internal cable routing, flat mount, 142×12 thru-axle, removable fender bridge, hidden rack/fender mounts
• ForkSynapse Carbon, integrated crown race, 12x100mm thru-axle, internal routing, flat mount brake, fender mounts
• HeadsetIntegrated, 1-1/8″ – 1-1/4″

Drivetrain

• Rear DerailleurShimano Tiagra GS
• Front DerailleurShimano Tiagra
• ShiftersShimano Tiagra, 10-speed
• ChainShimano HG54, 10-speed
• CrankShimano Tiagra, 50/34
• Rear CogsShimano HG500, 11-34, 10-speed
• Bottom BracketShimano RS500

Brakes

• BrakesShimano Tiagra hydraulic disc, 160/160mm RT54 rotors
• Brake LeversShimano Tiagra

Wheels

• RimsDT Swiss R470 DB, 28h, tubeless ready
• SpokesStainless Steel, 14g
• TiresVittoria Zaffiro Pro Bright Black, 700x30c, reflective
• Tire Size30
• Wheel Size700c
• Hubs(F) Formula CL-712, 12x100mm centerlock / (R) Formula RXC-400, 12x142mm centerlock
• Front TireVittoria Zaffiro Pro Bright Black, 700x30c, reflective
• Rear TireVittoria Zaffiro Pro Bright Black, 700x30c, reflective

Components

• HandlebarCannondale 3, 6061 Alloy, Compact
• StemCannondale 3, 6061 Alloy, 31.8, 7°
• GripsCannondale Bar Tape, 3.5mm
• SaddleFizik Aliante Delta, S-alloy rails
• SeatpostCannondale 3, 6061 Alloy, 27.2x350mm

Connectivity

• Wheel SensorCannondale Wheel Sensor

Extra

• Extra 1Toptube Bag, Trainer Axle
